High-Voltage Power SupplyIon Pump Controller
2800~5000 V adjustable · sub-nA current measurement · Modbus remote monitoring
A smart high-voltage supply for miniature ion pumps and UHV systems. Its single output adjusts from 2800 to 5000 V in 100 V minimum steps with voltage stability better than 2%, while 0.1 nA-level current measurement converts ion current into a live vacuum readout (10⁻³~10⁻¹¹ Pa, switchable to Torr or mbar) — no separate gauge required. Operate locally on the 3.5-inch color touchscreen (auto brightness and sleep), or connect a host computer over USB Type-B or Ethernet — with modbus-rtu and modbus-tcp support — to read voltage, current and pressure and configure parameters. A front-panel hardware HV enable switch (lit green when output is allowed) cuts high voltage when released and locks out remote turn-on; the unit is powered over USB Type-C (15 V / 12 V) and can run from a vehicle or battery supply. It is the standard companion controller for LinQ's miniature combination ion pump, and is also available separately.
Key Features
A high-voltage supply, a vacuum gauge and a remote-monitoring terminal in one box.
Hardware HV Enable Switch
A metal front-panel enable switch: pressed and lit green, high voltage is allowed; released, HV is cut and locally locked out so it cannot be switched on remotely — one press makes cable work safe.
Wide-Range Adjustable HV
Single 2800~5000 V output in 100 V minimum steps, stability better than 2%; to change the target voltage while running, switch HV off first and set the new value.
Sub-nA Current Measurement
0.1 nA-level current resolution converts ion current directly into vacuum readout across 10⁻³~10⁻¹¹ Pa, switchable to Torr or mbar.
Touchscreen + Remote Control
3.5-inch color touchscreen for local operation (auto brightness and sleep); USB Type-B or Ethernet host link with modbus-rtu / modbus-tcp support to read voltage, current and pressure and set parameters.
Comprehensive Output Protection
Max output current ≥200 µA at 5000 V; over-current, over-voltage and under-voltage protection safeguard both pump and supply.
Works With LinQ Products
The standard companion controller for LinQ's miniature combination ion pump; offered as a benchtop instrument or an embedded module for OEM systems.
Specifications
Contact us for the full datasheet.
| Intended Load | Positive-polarity ion pumps up to 5 L/s (incl. LinQ's miniature combination ion pump) |
|---|---|
| Output Channels | 1 |
| Output Voltage | 2800~5000 V adjustable (100 V min. steps) |
| Voltage Stability | Better than 2% |
| Max Output Current | ≥ 200 µA @ 5000 V |
| Output Protection | Over-current, over-voltage and under-voltage protection |
| Current Display Resolution | 0.1 nA level |
| Pressure Readout Range | 1×10⁻³ ~ 1×10⁻¹¹ Pa (switchable Torr / mbar) |
| Display & Controls | 3.5-inch color touchscreen (auto brightness & sleep); HV enable switch with green indicator |
| Host Interface | USB Type-B / Ethernet (modbus-rtu & modbus-tcp) |
| Power Input | USB Type-C power (15 V / 12 V) |
| HV Connector | HV SHV BNC (5 kV class), 3 m HV cable included |
| Cooling | Natural convection / optional fan |
| Form Factor | Benchtop instrument / embedded module (size customizable) |
Application Fields
Ion Pump Operation
The standard supply for miniature combination ion pumps — high voltage, current measurement and vacuum display in one unit.
Portable & Transport Scenarios
Low-voltage 15 V / 12 V power from a vehicle or battery supply keeps vacuum alive during system transport and outages — suited to portable quantum-sensing instruments.
Remote Monitoring & Automation
Connect to a host over modbus-rtu / modbus-tcp to read voltage, current and pressure and control HV remotely — ideal for long-term unattended vacuum monitoring.
Laboratory UHV Systems
HV supply and vacuum monitoring for cold-atom setups, surface-science and analytical instruments with compact UHV chambers.
OEM Integration
The module variant drops the human interface and runs entirely over its data interface — ready to embed in quantum systems and automated equipment.
A smart supply for your ion pump
Want custom form factors, the communication protocol, or volume pricing? Get in touch with our team.
Contact us
